| Functions | DG Synchronization With Grid Parallel, Power Export/Import Control, Digital load share, 32 Genset with Grid parallel, Load VAR Sharing, LDSS. |
|---|---|
| Name | Synchronization & Load Sharing Controller |
| Auxiliary Voltage | 8 to 40 V DC |
| Power Consumption | 12 W |
| Digital Outputs | 12 |
| Digital Inputs | 12 |
| Mounting Type | Door Mounting |
| Degree of Protection | Front - IP66, Back - IP20 |
| Nominal Frequency | f-50 / f-60 |
| Analog Inputs | 3 |
| Analog Outputs | 2 |
| Functions | DG Synchronization With Grid Parallel, Power Export/Import Control, Digital load share, 32 Genset with Grid parallel, Load Shedding, Load Depending start/stop, breaker modes, etc. |
|---|---|
| Name | Synchronization & Load Sharing Controller |
| Auxiliary Voltage | 8 to 40 V DC |
| Power Consumption | 12 W |
| Digital Outputs | P1 - 12; P2 - 22 |
| Digital Inputs | P1 - 12; P2 - 23 |
| Mounting Type | Door Mounting |
| Degree of Protection | Front - IP66, Back - IP20 |
| Nominal Frequency | f-50 / f-60 |
| Analog Inputs | P1 - 3; P2 - 10 |
| Analog Outputs | P1 - 2; P2 - 6 |
